Model

P1.875

P2

P2.5

P3

P4

Pixel Pitch(mm)

1.875mm

2.0mm

2.5mm

3mm

4mm

Pixel Configuration

SMD1010

SMD1010

SMD2020

SMD2020

SMD2020

Pixel Density(pixel/sqm)

284444

250000

160000

111111

62500

Brightness(cd/sqm)

600

600

800

1000

1000

Scanning Method

1/32

1/30

1/32

1/24

1/15

Module Dimension(mm)

240*120

240*120

240*120

240*120

240*120

Cabinet Dimension(mm)

960*960

960*960

960*960

960*960

960*960

Cabinet Material

Steel

Cabinet weight(kg)

46

Cabinet Resolution(pixels)

512*512

480*480

384*384

320*320

240*240

Refresh rate(HZ)

3840

Viewing angle

H:160 V:120

Protection grade(fromt/back)

IP30

Max power consumption (W/sqm)

462

380

380

450

450

Average power consumption(W/sqm)

182

150

150

180

180

Input Voltage(V)

100V or 240V, 50 or 60Hz

Grey Level

16bit

Working Temperature

-20-50℃

Working Humidity

10%-90%
