Model | OFC 6.67 | OFC 8 | OFC 10 |
Pixel Pitch(mm) | 6.67mm | 8mm | 10mm |
Pixel Configuration | SMD2727 | SMD3535 | SMD3535 |
Pixel Density(pixel/sqm) | 22477 | 15625 | 10000 |
Brightness(cd/sqm) | 5500-6000 | 5500-6000 | 6500 |
Scanning Method | 1/5 | 1/5 | 1/2 |
Module Dimension(mm) | 320*160 | 320*160 | 320*160 |
Module Resolution(pixels) | 48*24 | 40*20 | 32*16 |
Cabinet Dimension(mm) | 960*960*120 | 960*960*120 | 960*960*120 |
Cabinet Resolution(pixels) | 144*144 | 120*120 | 96*96 |
Max power consumption (W/sqm) | 790 | 690 | 840 |
Average power consumption (W/sqm) | 260 | 230 | 280 |
Cabinet Material | Die Cast Magnesium | ||
Cabinet weight(kg) | 30 | ||
Refresh rate(Hz) | 1920 or 3840 | ||
Viewing angle | H:120 V:120 | ||
Protection grade(fromt/back) | IP65 | ||
Input Voltage(V) | 110V/220V, 50/60Hz | ||
Grey Level | 14-16 bit | ||
Working Temperature | -20-50℃ | ||
Working Humidity | 10%-90% |
