1

Product Type

TBI-1.9

TBI-2.8

TBI-3.9

TBI-4.8

TBO-3.9

TBO-4.8

TBO-5.6

TBO-6.2

2

Pixel Pitch (mm)

P1.95

P2.84

P3.91

P4.81

P3.91

P4.81

P5.68

P6.25

3

Module Size (mm)

250X250X
15

250X250X
15

250X250X
15

250X250X
15

250X250X
15

250X250X15

250X250X15

250X250X15

4

Module Resolution (pixels)

128x128

88x88

64x64

52x52

64x64

52x52

44x44

40x40

5

Cabinet Size (mm)

500x500x91

500x500x91

500x500x91

500x500x91

500x500x91

500x500x91

500x500x91

500x500x91

6

Cabinet Resolution (pixels)

256x256

176x176

176x176

128x128

128x128

104x104

88x88

80x80

7

Pixel Configuration

1RGB

1RGB

1RGB

1RGB

1RGB

1RGB

1RGB

1RGB

8

LED Encapsulation

SMD2020

SMD2020

SMD2020

SMD2020

SMD1921

SMD1921

SMD2727

SMD3535

9

Work Voltage（DC）

5V

5V

5V

5V

5V

5V

5V

5V

10

Driver Mode

1/32

1/22

1/16

1/13

1/16

1/16

1/11

1/4

11

Weight (kg)

8.8

8.8

8.8

8.8

8.8

8.8

8.8

8.8

12

Physical Density (Pixels/ m2)

262144

123904

65536

43264

65536

43264

30976

25600

13

Brightness (NIT)

800

1000

1000

1000

1000

5000

5000

5000

14

Gray Scale (BIT)

14

14

14

14

14

14

14

14

15

Contrast ratio

3000：1

3000：1

3000：1

3000：1

3000：1

3000：1

3000：1

3000：1

16

Refresh Rate (Hz)

3840

3840

3840

3840

3840

3840

3840

3840

17

Viewing Angle（H/V）

±140°/±140°

±140°/±140°

±140°/±140°

±140°/±140°

±140°/±140°

±140°/±140°

±140°/±140°

±140°/±140°

18

Protection Grade

IP30

IP30

IP30

IP30

IP65

IP65

IP65

IP65

19

Max Power Consumption (W/ SQM)

SQm2)

424

424

424

424

424

560

560

560

20

Average Power
Consumption (W/ SQM)

168

168

168

168

168

224

224

224

21

Work Temperature

-20℃～50℃

-20℃～50℃

-20℃～50℃

-20℃～50℃

-20℃～50℃

-20℃～50℃

-20℃～50℃

-20℃～50℃

22

Working Humidity

10%RH～95%RH

10%RH～95%RH

10%RH～95%RH

10%RH～95%RH

10%RH～95%RH

10%RH～95%RH

10%RH～95%RH

10%RH～95%RH

23

Optimal Viewing Distance (m)

≥3.5m

≥6.5m

≥8.5m

≥6.5m

≥8.5m

≥8.5m

≥8.5m

≥8.5m
