1 |
Product Type |
ELI MAX-2.8 |
ELI MAX-3.9 |
ELI MAX-4.8 |
ELO MAX -3.9 |
ELO MAX-4.8 |
ELO MAX-5.6 |
ELO MAX-6.2 |
2 |
Pixel Pitch (mm) |
P2.84 |
P3.91 |
P4.81 |
P3.91 |
P4.81 |
P5.68 |
P6.25 |
3 |
Module Size (mm) |
250X250X15 |
250X250X15 |
250X250X15 |
250X250X15 |
250X250X15 |
250X250X15 |
250X250X15 |
4 |
Module Resolution (pixels) |
88x88 |
64x64 |
52x52 |
64x64 |
52x52 |
44x44 |
40x40 |
5 |
Cabinet Size (mm) |
500x1000x88 |
500x1000x88 |
500x1000x88 |
500x1000x88 |
500x1000x88 |
500x1000x88 |
500x1000x88 |
6 |
Cabinet Resolution (pixels) |
176x352 |
128x256 |
104x208 |
128x256 |
104x208 |
88x176 |
80x160 |
7 |
Pixel Configuration |
1RGB |
1RGB |
1RGB |
1RGB |
1RGB |
1RGB |
1RGB |
8 |
LED Encapsulation |
SMD2020 |
SMD2020 |
SMD2020 |
SMD1921 |
SMD2727 |
SMD2727 |
SMD3535 |
9 |
Work Voltage（DC） |
5V |
5V |
5V |
5V |
5V |
5V |
5V |
10 |
Driver Mode |
1/22 |
1/16 |
1/13 |
1/16 |
1/13 |
1/11 |
1/5 |
11 |
Weight (kg) |
16 |
15 |
15 |
16 |
16 |
16 |
16 |
12 |
Physical Density (Pixels/ m2) |
123904 |
65536 |
43264 |
65536 |
43264 |
30976 |
25600 |
13 |
Brightness (NIT) |
800 |
800 |
800 |
5000 |
5000 |
5000 |
5000 |
14 |
Gray Scale (BIT) |
14 |
14 |
14 |
14 |
14 |
14 |
14 |
15 |
Contrast ratio |
3000：1 |
3000：1 |
3000：1 |
3000：1 |
3000：1 |
3000：1 |
3000：1 |
16 |
Refresh Rate (Hz) |
3840 |
3840 |
3840 |
3840 |
3840 |
3840 |
3840 |
17 |
Viewing Angle（H/V） |
±140°/±140° |
±140°/±140° |
±140°/±140° |
±140°/±140° |
±140°/±140° |
±140°/±140° |
±140°/±140° |
18 |
Protection Grade |
IP30 |
IP30 |
IP30 |
IP65 |
IP65 |
IP65 |
IP65 |
19 |
Max Power Consumption (W/ SQM) |
424 |
424 |
424 |
560 |
560 |
560 |
560 |
20 |
Average Power |
168 |
168 |
168 |
224 |
224 |
224 |
224 |
21 |
Work Temperature |
-20℃～50℃ |
-20℃～50℃ |
-20℃～50℃ |
-20℃～50℃ |
-20℃～50℃ |
-20℃～50℃ |
-20℃～50℃ |
22 |
Working Humidity |
10%RH～95%RH |
10%RH～95%RH |
10%RH～95%RH |
10%RH～95%RH |
10%RH～95%RH |
10%RH～95%RH |
10%RH～95%RH |
23 |
Optimal Viewing Distance (m) |
≥6.5m |
≥8.5m |
≥10m |
≥8.5m |
≥10m |
≥11.5m |
≥13m |
